K-Rain Sprinkler Repair in Ponte Vedra, Nocatee & St. Augustine

What we fix on K-Rain systems

• Rebuild or replace 4000/6000 indexing valves (cams, discs, diaphragms) and add check valves
• Replace RPS 75/ProPlus rotors; use RPS 75 as a drop-in for Hunter PGP cans
• Replace Pro-S sprays and nozzles; set arc and radius
• Rebuild ProSeries valves: solenoids, diaphragms, flow control
• Program PRO EX 2.0/PRO-LC/K-Rain Blue controllers and rain sensors
• Wire and size pump start relays
• Service well/pump-fed systems common in NE Florida

K-Rain problems we see most

• Indexing valve sends water to several zones at once (needs ~10 GPM; worn diaphragm, clogged intake or main-line filter)
• Indexing valve skips zones (pump suction leaks, valve too far from source)
• Indexing valve stuck / won't cycle from backflow (needs check valves on higher zones)
• Gear-drive rotor stops turning (sand/debris in the gear drive - clean filter or replace head)
• RPS75i no water with flow control off (riser pops but no flow)
• Pump start relay chattering (undersized wire or transformer)
• Controller won't run in AUTO or loses time (power/relay issues)

K-Rain products we work on

• RPS 75 rotor rotor
  3/4" gear-drive rotor with K-Rain's patented reversing mechanism, 40-360 degree arc, whose riser drops into existing Hunter PGP/PGP Ultra cans.
• ProPlus / SuperPro / MiniPro rotors rotor
  Professional rotor families listed on krain.com alongside RPS 50/75/Select.
• Pro-S spray body spray head
  2"-12" pop-up spray with co-molded wiper seal, ratcheting riser, heavy-duty spring and flush cap.
• Rotary & KVF/KV nozzles nozzle
  Rotary and adjustable fixed-pattern nozzle lines for spray bodies.
• ProSeries 100 electric valve valve
  3/4" and 1" valve with external bleed screw and optional manual flow control.
• 4000 / 6000 Series indexing valves valve
  Mechanical indexing valves that advance to the next zone each time flow stops and starts; 4000 for pump or city water, die-cast 6000 for high-pressure pump systems; up to 4 or 6 zones.
• PRO EX 2.0 / PRO-LC controllers controller
  PRO EX 2.0 expands to 28 stations with optional Wi-Fi; PRO-LC is a fixed 4/8/12-station controller with valve locate and rain/freeze sensor support.

Product names from K-Rain’s own site. Don’t see yours? Call us — if it waters a lawn, we’ve probably had it apart.
