Rain Bird Wi-Fi Controller Install & Repair in Ponte Vedra, Nocatee & St. Augustine

What we fix on Rain Bird Wi-Fi systems

• Install, replace or upgrade ESP-TM2, ESP-ME3 and ST8 controllers and transformers
• Add and pair the LNK2 WiFi module; set up the Rain Bird app and shared access for the homeowner
• Program schedules, seasonal adjust, rain delay, master valve/pump start settings
• Diagnose blown fuses and trace the shorted solenoid or field wire that caused them
• Wire and bypass rain/freeze sensors; add flow sensing on ESP-ME3
• Test 24 VAC at each station terminal and repair valves, solenoids and wiring
• Repair or replace Rain Bird heads, nozzles and valves on the same system

Rain Bird Wi-Fi problems we see most

• LNK/LNK2 module goes offline or blinks red: 2.4 GHz-only radio, controller at the edge of Wi-Fi range (common on garage/outside walls)
• App can't find the module during setup (phone on the wrong network or Location Services off)
• 'New Update Detected' error: module firmware must be updated before the app will connect
• Blown fuse / 'PR OFF' display after a shorted solenoid or valve wire fault
• Blank or frozen display after a power surge (reset button / power-cycle)
• Program repeats or runs twice because of extra start times
• Rain sensor or SENS-terminal issues stopping all zones
• Lost schedules after the Wi-Fi module is removed or the controller is factory reset

Rain Bird Wi-Fi products we work on

• ESP-TM2 controller
  Indoor/outdoor controller for up to 8 zones that becomes Wi-Fi enabled when the separately sold LNK WiFi module is installed.
• ST8-2.0 WiFi Smart Irrigation Timer (ST8I-2.0 indoor / ST8O-2.0 outdoor) controller
  8-zone Wi-Fi timer sold in indoor and outdoor versions, programmed from the Rain Bird app with automatic seasonal adjust; some models carry WaterSense certification.
• LNK2 WiFi Module controller
  Plug-in Wi-Fi module for LNK-Ready ESP-TM2, ESP-RZXe, ESP-ME3, ESP-ME (post Nov 2016), LXIVM and LXME2 controllers; 2.4 GHz networks only, set up through the Rain Bird app.
• ESP-ME3 controller
  LNK2-compatible modular controller with flow-sensing that can notify owners of a leak or water shortage.

JEA water customer? JEA pays a $150 rebate on a new WaterSense-labeled smart controller — rebate details · apply on jea.com. Product names from Rain Bird Wi-Fi’s own site. Don’t see yours? Call us — if it waters a lawn, we’ve probably had it apart.
